3G-SDI Splitter 1 in 4 out

3G-SDI Splitter 1 in 4 out allows four (4) SDI monitors to be connected to one (1) SDI (Serial Digital Interface) source signal. Split one SD-SDI (standard def), HD-SDI (high def) or 3G-SDI (3G) signal into four equalised and reclocked signals for connection to four 3G-SDI monitors. The operating speeds for the 3G-SDI Splitter 1 in 4 out are 2.970Gb/s and 2.970/1.001Gb/s, 1.485Gb/s and 1.485/1.001Gb/s, 270Mb/s with transmission distances up to 100m for 3G-SDI, 200m for HD-SDI and 300m for SD-SDI. Easy to instal and operate, no software required, simply plug'n'play

The 3G-SDI Splitter 1 in 4 out gives full support for SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292M, SMPTE 259M-C signalling. SDI is a serial link originally standardized by SMPTE 259M. It is used to transmit uncompressed digital video over coaxial cable and has a maximum data rate of 360Mb/s. HD-SDI is the second-generation version of SDI and allows transmission of HD (1080i and 720p) signals over the same cables as SD-SDI. It handles rates up to 1.485Gb/s. 3G-SDI is the latest version of SDI and allows transmission of 1080p60 HD signals (with a 4:2:2 sampling structure at 10 bits per sample) over a single coax cable. Defined by SMPTE 424M, the single-link studio interface can reach a maximum bit rate of 2.97Gb/s.

Ideal for use in Professional fields such as Television and Recording Studios, Education and Advertising, or for use with private Home Theatre systems, the 3G-SDI Splitter 1 in 4 out is a cost effective way to display a Serial Digital Interface signal source to multiple SDI monitors. To learn more about the 3G-SDI Splitter 1 in 4 out, please click hereto access the product webpage. You may order and make payment through this page, or you may contact our friendly Sales Staff for any assistance you may require Phone: +61 2 4968 9313, by Fax: +61 2 4968 9314 or email sales@converters.tv
